Aveo Powerburst Ng Daylite Light Set - Green / Red / White

Select Base Color
Black BaseWhite BaseRed/Green Base
Quantity
Add to Wishlist

Overview

At only 26 millimeters in height (1.024 inch) the new PowerBurst NG™ DayLite is a value light that does not sacrifice anything in performance or standards as other economy-priced lights offered by the competition

The exclusive and highly advanced optics and chrome reflector system, unmatched power and LED management circuitry, and Aveo's famous lowest-drag profile in the industry are all combined into a product that gives you unmatched POWER and FEATURES. Lower, narrower and shorter PLUS much lighter than industry lights in this category!

For Experimental Use Only. Not approved for installation on certified aircraft. This is not a TSO certified light.

Features

  • 3-in-1 Nav/Position/Strobe
  • Extremely lightweight
  • Unmatched circuit technology
  • Waterproof
  • Vibration-proof
  • Shock-proof
  • Dust-proof
  • Limited 3yr Warranty - Product must be registered within 30 days of purchase Here

Specifications

  • Dimensions (mm): 115 mm x 33 mm x 26 mm
  • Dimensions (inches): 4.547” x 1.302” x 1.024”
  • Weight: 70 g / 2.47 oz
  • Operating Voltage Range: 9 – 18 V DC
  • Input Current – Position / Nav - green (@14V): 0.28 A
  • Input Current – Position / Nav - red (@14V): 0.23 A
  • Input Current – Strobe (@14V): 2 A peak
  • Output Power - Position / Nav - green: 3.3 W
  • Output Power - Position / Nav - red: 2.5 W
  • Output Power - Strobe: 24 W peak
  • Repetition Rate of Strobe: 50 cycles per minute
  • Recommended size of mounting screw: M3, stainless steel recommended. Length depends upon placement location on wing tips.
  • Ambient Temperature: From -40°C to +85°C, -40°F to +185°F
  • Overheat Protection: Yes
  • Reverse Polarity Protection: Yes
  • Transient Voltage: No
  • Under-Voltage Protection: No
  • Over-Voltage Protection: No
  • Waterproof, Dust-proof, Shock-proof, Vibration-proof: Yes

Documents

  • Customers Also Viewed
  • Frequently Purchased With
  • Related Items

Reviews

This is my second set. The strobe stopped working on one lite with only 87 flight hours of use. Strobe was not used at all times so had considerably less time. New ones seem to be built differently. So hope for more longevity

Harold B Verified Purchase

AVEO POWERBURST DAYLITE GRN-RED-WHITE STROBE KIT

February 12, 2022

love them, super easy instal

Nathan P Verified Purchase

AVEO POWERBURST DAYLITE GRN-RED-WHITE STROBE KIT

February 9, 2022

Havent tried them yet but look nice and got the black base . Quality product.

Robert M Verified Purchase

AVEO POWERBURST DAYLITE GRN-RED-WHITE STROBE KIT

February 3, 2022

Excellent wing tip lights for brightness with strobe & nav & position. Working well on my Arion Lightning, following replacement of old system. Would recommend. Box did not include mounting screws or threaded base plate, but used long 6/32 screws & tapped anckor plate ok.

David
November 24, 2021

works well and is a great value.

Thomas F Verified Purchase

AVEO POWERBURST DAYLITE GRN-RED-WHTE W/ RED/GREEN BASE

October 12, 2021

The Aveo Powerburst is easy to install and significantly brighter and lighter than my old Whelen strobe system. The only downside for my application was the hole pattern on the new unit did not match my old strobe installation. That was solved by fabricating a tear shaped mounting plate to go between the Aveo and old wing tip surface. This allowed me to match the old hole pattern and add nut plates to secure the new lights, thus avoiding fiberglass and sanding a new mounting surface. I suspect the average install will not need this step and mount more conveniently.

F. M
December 8, 2020

Aveo=great customer service

Donald D
September 24, 2020

Very easy installation. Had to make a mounting plate for my Cozy. Much brighter navigation lights than old Whelan system.

Patrick
August 10, 2020

Nice unit, very bright strobe!

David L
July 6, 2020

Not installed yet but are very bright. They’re going work great on my RANS S-19

John M
August 9, 2019

Q&A

Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: The Aveo Powerburst is listed for 14V applications. Will this work in a 12V system? Regarding 05-04877

Yes, 14V sets can be used in 12V systems as they are essentially interchangable.

Q: What are the dimensions of 05-04877? Thank you.

Please review the Dimensional Drawing found in the "Documents" tab of this web page.

Q: This site on one page says it is water proof and vibration proof. On another page it says water and vibration resistant. Which is it water / vibration proof or water / vibration resistant?

We have updated our web page to be consistent with the manufacturer's. All listings of this information now say "waterproof and vibration proof" which is consistent with manufacturer's listing.

Q: If the sync wire is omitted from the installation, does the Aveo Powerburst light system still function normally, except, that is, with the left and right strobes out of sync?

The blue wire is an optional sync feature. The lights are closely matched at the factory but they will, over cycling, end up out of sync if the blue wires are not connected between the lights. If you don't care about syncing then there is no need to connect the blue wires.

Q: I have a 12V system but when the engine is running my gage is showing 14.6V. Is that within the acceptable range?

Yes, this is within the operating range for this light set.

Q: Regarding Part # 05-04877 (AVEO POWERBURST GREEN-RED-WHITE): Do the position lights (Red/Green) flash or just stay constant on?

The tech data sheet only shows the strobe (white) flashing. The red / green lights do not flash.

Q: What is the repetition rate of this strobe? How many flashes per second?

Repetition Rate of Strobe: 50 cycles per minute. This would equal 1.2 flashes per second.

Q: Aveo shows this as the PowerBurst Plus. Are you selling the newer model or the older (non-Plus) model?

The Aveo Powerburst(05-04877) is the DayLite model.

Q: How many candela is the nav light and how many candela is the strobe?

Aveo does not provide candela information. They state that the candela depends on lab resting conditions.

Q: Can the strobes be tuned off separately from the red and green nav lights? So they are not constantly on when the nav lights are on.

The nav lights have a separate power supply than the strobe. You can wire two switches to operate independently.
